innoSens 550 Ammonia Electrode

The innoSens 550 ammonia nitrogen electrode uses the ion-selective electrode method to measure the concentration of ammonia nitrogen in water. The ammonia ion-selective electrode is used to directly detect ammonium ions in the water environment to determine the concentration of ammonia nitrogen. The ammonia nitrogen sensor uses a pH electrode as a reference electrode, resulting in better stability. The sensor is also susceptible to interference from potassium ions, so when the potassium ion concentration in water is high, an optional potassium ion electrode is available for automatic compensation.




Features
The innoSens 550 ammonia sensor consists of an ammonium ion electrode, a potassium ion electrode (optional), a pH electrode and a temperature electrode in a single sensor, which can be used to correct for each other and for multiple parameters at the same time.
specifications
Measuring range:NH4-N: 0.1-1000 mg/L
PH: 5 - 10 pH
Temperature:  0 - 40℃
Accuracy:NH4-N: ±5% of measured value
pH: ±0.1 pH
Temperature: ±0.2℃
Repeatability: ±3% of measured value
Response time: <2min
Lifetime:6 months for diaphragm,
3 months for electrolyte
Working temp:2-40℃
Protection class: IP68

Dimensions: φ62mm×353mm


Order No. Description

35-0550-00 innoSens 550-R1 Ammonia Electrode, Cable 10m

35-0550-10 innoSens 550-R2 Ammonia/Potassium Ion, Cable 10m

download

innoSens 550
