Flumsys 10TC-T5 Turbidity Analyzer

Features

Single-channel measurement, need to select the corresponding sensor

Wide power input, touch screen design

 4.3-inch colour touch screen displays measured value, temperature and relay status

Chinese/English menu, easy to operate

Password protection to prevent unauthorised operation

New calibration step-by-step prompts can help reduce operating errors

2x programmable Hi/Lo relay outputs

Programmable auto-purge relay outputs

2x isolated 4-20mA outputs

RS485 Modbus RTU communication
Data storage function, support for USB stick data expor

Features

Controller

Display: 4.3" colour LCD touch screen display
Language:Chinese/English
Password: Setting mode:0022,Calibration mode:0011
Power supply:110-240VAC,50/60Hz.
Current output 1: Isolated 4-20mA output, settable measurement value, maximum load 500Ω
Current output 2: isolated 4-20mA output, settable measurement value, max. load 500Ω
Digital communication: RS485 Modbus RTU
Alarm output: 2 sets of programmable Hi/Lo contacts with hysteresis setting
Purging relay: 5A/250VAC/30VDC
            Cleaning interval:0.1-1000h,cleaning time:1-1000s
Operating temperature:-10~60.0°C
Storage temperature:-20~70.0°C
Protection level:IP66
Mounting: Wall mounted
Dimensions:200 x 180 x 90mm
Weight:ca. 1Kg

SENSOR

innoSens 850T Low Range Turbidity Sensor

Measurement principle: 90° scattered light
Measurement range: 0.0001-100NTU
Resolution: 0.0001/0.01/0.01NTU
Accuracy: ±2% of reading or 0.02NTU, whichever is greater
Light source: LED
Power supply: 90-260VAC, 50/60Hz, 24VDC optional
Display: LCD backlit display of measured value, temperature and relay status
Language: Chinese/English
Analogue output: Isolated 4-20mA output (turbidity), Max. 600Ω
Digital communication: RS485 Modbus RTU
Alarm output: 2 sets of independently set Hi/Lo alarm points with hysteresis setting
Protection class: IP65
Water flow rate:: 100-200ml
Operating temperature: 0 - 50°C
Mounting: Wall mounted
Dimensions: Sensor: 160 x 260 x 150mm
Weight: controller: ca.1Kg, sensor: ca.2Kg
