innoCon 6800T-5 Low-range online turbidity analyser

Parameters

Turbidity: 0.0001 - 100 NTU

Applications: drinking water, boiler water, process water, swimming pools

Features

90° scattered light principle in accordance with ISO 7027
Easy installation with bubble elimination tank
Anti-condensation function for high accuracy measurement
Wide power input, touch screen design
Large backlit LCD display showing measured values, temperature and relay status
Chinese/English menu for easy operation
Password protection to prevent unauthorised operation
New calibration step-by-step prompts to help reduce operational errors
2 x programmable Hi/Lo relay outputs
Programmable auto-purge relay outputs
2 x isolated 4-20mA outputs
RS485 Modbus RTU communication
Data storage capability with USB stick export support

Features

Controller

Display: 4.3" colour LCD touch screen display
Language:Chinese/English
Password: Setting mode:0022,Calibration mode:0011
Power supply:110-240VAC,50/60Hz.
Current output 1: Isolated 4-20mA output, settable measurement value, maximum load 500Ω
Current output 2: isolated 4-20mA output, settable measurement value, max. load 500Ω
Digital communication: RS485 Modbus RTU
Alarm output: 2 sets of programmable Hi/Lo contacts with hysteresis setting
Purging relay: 5A/250VAC/30VDC
            Cleaning interval:0.1-1000h,cleaning time:1-1000s
Operating temperature:0~70.0°C
Storage temperature:-20~70.0°C
Protection level:IP65
Mounting: Wall mounted
Dimensions:200 x 180 x 90mm
Weight:ca. 1Kg

SENSOR

The InnoSens 850T low range turbidity sensor measures ultra-low range turbidity and has an internal defoaming structure and anti-condensation function to ensure stable, high accuracy measurements. The LED light source does not need to be replaced within ten years and is widely used for online monitoring of turbidity in all types of clean water such as tap water outlets and engineering drainage outlets.

Digital Sensors

Product type: innoCon 6800T-5

Measurement principle: 90° scattered light

Measurement range: 0.0001-100NTU

Resolution: 0.0001/0.001NTU

Accuracy: ±2% of reading or ±0.02NTU, whichever is greater

Light source: LED

Response time: <30s

Inlet water flow: 100-200ml/min

Operating temperature: 0-50°C

Protection level: IP65

Installation: wall mounted

Size: 160x260x150mm

Weight: ca.2Kg
